Reach Truck

RT 15ST The Stand-on Reach Stacker Designed for Most Demanding Applications

RT 15ST Series Reach stacker is an ideal option for high capacity and high lift height cargo storage application. Rated load capacity of 1500kgs , lifting height up to 8 Meters. It has the advantages of the integrated reach forward mast and small turning radius, which can ignore the barriers of the bottom shelf. It is applicable to large-scale vertical chemical plants, warehouses, supermarkets, docks and places for goods storage

Regenerative braking

If brake when driving, the motor automatically powers off to maximize reduce power consumption and extend battery working time; The use of regenerative braking technology minimize the wear of braking efficiently, to ensure the brake safety and efficiency of energy recovery.

Advanced configuration

Integrated AC system, KDS motor, Zapi power steering and control systems with high-precision gearbox to ensure a flexible steering and high-quality driving performance.

Hydraulic system

International advanced connectors, hoses beautiful design Safe and convenient configuration and abrasion resistance, high temperature, resistance, high flexible import seals, which reasonable layout of hard and soft tube to ensure that the whole hydraulic system cooling, sealing, durability, safety and efficiency.

Comfortable and beautiful design

Modern and new design in Modern design of control pedal, and the damping pedal with ergonomic design ensures comfortable driving

Mast system

The mast has the reach forward function which allows the truck to store the goods without moving the truck itself, which is convenient and safe; High quality imported C-shape mast ensures the integrity of vehicle load capacity.

Emergency button

Safe and convenient configuration of the emergency button, emergency one-time cut off all energy,   greatly increase safety.

Safety

The mast piping system with safe speed limit valve, effectively control the rate of lowering of goods. High standards of craftsmanship, arterials and quality ensures better performance in harsh conditions.

Buffer system for fork lowering and mast forward/backward

Buffer system for fork lowering and mast forward / backward increase vehicle safety and operating comfort

Electronic control functions

The electrical energy, timing, fault display is easy for operator to understand the vehicle condition and to have maintenance. The surface of electrical components is water and dust proof, the design of fully enclosed thermal of the central control unit to make the circuit simpler and more reliable.
