| Model |
EFG 16XE3 E4/EFG 20XE3 E4/EFG 25XE3 E4/EFG 30XE3 E4/EFG 35XE3 E4/EFG 40XE3 E4 |
|---|---|
| Type of Forklift |
Electric |
| Capacity |
3,0 - 4,0 T |
| Engine |
ZAPI / CURTIS |
| Mast |
2 stage 3M to 3 Stage 4.5M |
| Tyres |
Solid Anti-Static |
|
Explosion-protected Electric Forklift for large payloads
|
|
| Suitable for use in Ex-zones 1, 2 and 21, 22, according to ATEX directive 94/9/EC. Registered and type-tested by the Physikalisch-Technische Bundesanstalt (PTB). Marking:  2G IIB +H2 T120° II 2D IP6x T115° |
| Model | Max. Load Capacity | Dead Weight | Dimensions (LxW) |
| EFG 16XE3 E4 | 1.600 kg | 4,2 t | 3,4 m x 1,2 m |
| EFG 20XE3 E4 | 2.000 kg | 4.2 t | 3,4 m x 1,2 m |
| EFG 30XE2 E4 | 3.000 kg | 4,9 t | 3,7 m x 1,2 m |
| EFG 35XE2 E4 | 3.500 kg | 5,8 t | 3,8 m x 1,2 m |
| EFG 40XE2 E4 | 4.000 kg | 6,3 t | 3,8 m x 1,2 m |
